Features
PURLED™
boosts light output by 25%, distributes light 6 times better and improves energy efficiency by 88%.
Additional Features
HYBRID FILTER
Hybrid filter issued from the combination of two filtering technologies, designed to capture 28% more grease.
Specifications
General
Series Name
IC700
Blower Included
Yes
Airflow
700 CFM
Style
Chimney
Color
Custom
Manufacturer Color
Custom
Installation
Wall Mount
Features
Ducting Information
Rectangular
Speeds
4
Additional Information
• 180 CFM at low speed, horizontal discharge
• 500 CFM at high speed, horizontal discharge (if needed, ask a recommended installer to limit discharge to 300 CFM)
• Sone (low speed horiz. & vert.) 2
• Sones (high speed horiz.) 10.5
• 2 LED modules 120 V, 5.5 W
• 500 CFM at high speed, horizontal discharge (if needed, ask a recommended installer to limit discharge to 300 CFM)
• Sone (low speed horiz. & vert.) 2
• Sones (high speed horiz.) 10.5
• 2 LED modules 120 V, 5.5 W
Electrical Information
Information
120 V
Certifications and Approvals
Hvi Certified
Yes
Energy Star Certified
No
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
27.37 inch(es) / 69.53 cm
Depth
20.75 inch(es) / 52.71 cm
Warranty
Warranty
Limited 5 years warranty parts and labor (except LED modules, 3 years)
