Features
QUICK WASH CYCLE
The Quick Wash cycle cleans small, lightly soiled loads in 30 minutes with extra high spin speeds, pairing nicely with the Quick Dry cycle on matching Maytag® dryers to get your clothes ready in no time.
AMERICAN PRIDE
We take pride in building strong, reliable appliances for your home. Better Built by hard-working employees and delivered straight from Clyde, Ohio to you, these washers are designed, engineered and assembled in the U.S.A.
STAINLESS STEEL WASH BASKET
This washer features a stainless steel wash basket that adds a polished, premium look and feel.
Additional Features
DRAW DISPENSER
The drawer dispenser delivers powerful cleaning, attacking everyday tough soils early in the cycle, by mixing detergent—liquid or powder—with water then dispersing thoroughly throughout the load.
SLOW-CLOSE GLASS LID
The slow-close glass lid offers a clear view of laundry and quiet, precision closing.
ADVANCED VIBRATION CONTROL™
Advanced Vibration Control™ Plus features two ball-bearing balancing rings, a six-point suspension system and advanced software that help stabilize loads of nearly any size.
AUTO SENSING OPTION
Fight everyday stubborn stains with the Auto Sensing option, which adjusts the water level for each load to provide efficient, concentrated cleaning.
POWER™ IMPELLER
The active Power™ Impeller keeps clothes thoroughly saturated with a triple action spray, for deep cleaning.
EXTRA RINSE OPTIONS
Add additional rinses to your cycle for optimal cleaning. An Extra Rinse adds a secondary, deep rinse to the cycle while the Fabric Softener option should be used to release fabric softener at the end of the cycle.
WRINKLE CONTROL CYCLE
Maxima® washers have a Wrinkle Control cycle that is designed to help keep wrinkles from forming in the wash.
CLEAN WASHER WITH AFFRESH® CYCLE
Run the affresh® cycle every 30 washes with an affresh® washing machine cleaner tablet or liquid chlorine bleach to thoroughly clean the inside of your washer.
Specifications
General
Wash Action System
Impeller
Color
White
Manufacturer Color
White
Tub Material
Stainless Steel
Maximum Speed
750 rpm
Temperature Settings
5
Capacity
Total Capacity IEC
5.5 cu. ft.
IEC (By Class)
4.3 cu.ft. and above
Cycle Information
Number of Cycles
10
Wash Cycles
• Bulky Items
• Clean Washer with affresh
• Delicates
• Drain & Spin
• Heavy Duty
• Normal
• Quick Wash
• Towels
• Whites
• Wrinkle Control
• Clean Washer with affresh
• Delicates
• Drain & Spin
• Heavy Duty
• Normal
• Quick Wash
• Towels
• Whites
• Wrinkle Control
Options
• Deep Fill
• Extra Rinse
• Fabric Softener
• Temperature
• Extra Rinse
• Fabric Softener
• Temperature
Features
Technologies
• Advanced Vibration Control™
• Automatic Load Size Sensing Technology
• Automatic Load Size Sensing Technology
Control Lock
Yes
Stackable
No
Reversible Door
No
Dispensers
• Single Dose
• Detergent
• Fabric Softener
• Bleach
• Detergent
• Fabric Softener
• Bleach
Additional Information
• Lid/Door lock
• Slow close lid
• Adjustable feet
• Lid/Door finish: Edge Glass
• Wash action: Impeller
• Motor horsepower: 1/3 HP
• Automated dispenser: Drawer
• Out of balance sensing
• Suspension system: 4 Springs 4 Dampers, Liquid filled upper balance ring
• Motor drive type: Belt
• Drum rear/Base material: Plastic
• Automatic temperature controls
• Control type: Knobs
• Control location: Rear console
• Electronic display type: LED
• LED color: White
• Feedback-status indicators: Done, Rinse, Sensing, Spin, Wash
• Number of soil levels: 3
• Number of spin speeds: 3
• Temperature selections: Hot, Cold, Tap Cold, Cool, Warm
• Soil selections: Light, Normal, Heavy
• Slow close lid
• Adjustable feet
• Lid/Door finish: Edge Glass
• Wash action: Impeller
• Motor horsepower: 1/3 HP
• Automated dispenser: Drawer
• Out of balance sensing
• Suspension system: 4 Springs 4 Dampers, Liquid filled upper balance ring
• Motor drive type: Belt
• Drum rear/Base material: Plastic
• Automatic temperature controls
• Control type: Knobs
• Control location: Rear console
• Electronic display type: LED
• LED color: White
• Feedback-status indicators: Done, Rinse, Sensing, Spin, Wash
• Number of soil levels: 3
• Number of spin speeds: 3
• Temperature selections: Hot, Cold, Tap Cold, Cool, Warm
• Soil selections: Light, Normal, Heavy
Electrical Information
Information
• 120 Volts
• 60 Hz
• 6 Amps
• 60 Hz
• 6 Amps
Accessories
Included
• Drain hose
• Power cord
• Power cord
Dimensions
Class Width
28" - 30"
Width
27.5 inch(es) / 69.85 cm
Height
42 inch(es) / 106.68 cm
Depth
27.5 inch(es) / 69.85 cm
Weight
142.99 lb(s) / 64.86 kg
Additional Dimensions
• Height to top of cabinet: 38
• Maximum height: 42 11/16
• Maximum height: 42 11/16
Shipping Dimensions
Width
29 inch(es) / 73.66 cm
Height
46 inch(es) / 116.84 cm
Depth
29.25 inch(es) / 74.3 cm
Weight
148 lb(s) / 67.13 kg
Warranty
Warranty
• 1-Year on parts and labor
• 10-Year limited parts warranty on the direct drive motor and stainless steel wash basket
• 10-Year limited parts warranty on the direct drive motor and stainless steel wash basket
UPC
UPC#
883049583211
