Features
COMBI-STEAM OVEN
The Combi-Steam oven combines the best of traditional cooking with steam, allowing you to cook as you’ve always done but with better results. Thanks to this combined technology, it reduces preparation time and energy consumption, while keeping food juicier and more nutritious.
VENTILATION INNVENT
Our patended INNVENT system with double inverted rotation of the fans distributes heat evenly throughout the oven’s cavity, not only vertically on different levels, but also horizontally on each level, allowing impeccable and homogeneous cooking. Your oven door can remain closed all the cooking time, because you won’t have the need to rotate the tray halfway.
ADVANCED TFT DISPLAY
The advanced electronic programmer features a user-friendly TFT display and ensures precise temperature control throughout cooking. It offers 11 distinct cooking functions plus 2 special modes: proofing for perfect dough rising and steam cleaning for effortless maintenance. Preset recipes are included to guide you through various cooking methods with professional results.
Specifications
General
Series Name
Ascot
Fuel Type
Electric - Induction
Installation Type
Freestanding
Color
Grey
Manufacturer Color
Antracite with Ottone Trim
Cooktop
Burners/Elements
5
Burners/Elements Output
• Total cooking zones: 5 (3 single + 2 flex)
• Zone 1 – Front left: 1.85 kW – 3 kW
• Zone 2 – Rear left: 1.85 kW – 3 kW
• Zone 3 – Center: 2.3 kW – 3.7 kW
• Zone 4 – Front right: 2.10 kW – 3.7 kW
• Zone 5 – Rear right: 2.3 kW – 3.7 kW
• Zone 1 – Front left: 1.85 kW – 3 kW
• Zone 2 – Rear left: 1.85 kW – 3 kW
• Zone 3 – Center: 2.3 kW – 3.7 kW
• Zone 4 – Front right: 2.10 kW – 3.7 kW
• Zone 5 – Rear right: 2.3 kW – 3.7 kW
Elements
Smoothtop
Oven
Capacity (cu. ft.)
3.2 cu. ft.
Number of Ovens
Single
Programs
• Defrost
• Static
• Upper Element
• Static Steam
• Grill
• Ventilated Grill
• Fan Steam
• Convection
• Fast Heating
• Proof
• Static
• Upper Element
• Static Steam
• Grill
• Ventilated Grill
• Fan Steam
• Convection
• Fast Heating
• Proof
Features
Technologies
• Induction Technology
• Convection Technology
• Patented INNVENT system
• Combi-Steam oven
• Convection Technology
• Patented INNVENT system
• Combi-Steam oven
Control Lock
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• 3 Interior Lights
• Kitchen Timer
• Bake/Broil: 1000 + 2800 W
• convection Element: 2500 W
• Lower Element: 1400 W
• Soft closing hinges gently guide the door shut so the oven door never slams
• Full extension telescopic rack rails for easy access to the oven cavity
• Removable dishwasher-safe stainless steel oven liners
• Kitchen Timer
• Bake/Broil: 1000 + 2800 W
• convection Element: 2500 W
• Lower Element: 1400 W
• Soft closing hinges gently guide the door shut so the oven door never slams
• Full extension telescopic rack rails for easy access to the oven cavity
• Removable dishwasher-safe stainless steel oven liners
Electrical Information
Information
• Circuit breaker: 50 A
• Voltage: 120 / 240 V
• Frequency: 60 Hz
• Power cord length: 4’
• Plug type: NEMA 50-14P
• Voltage: 120 / 240 V
• Frequency: 60 Hz
• Power cord length: 4’
• Plug type: NEMA 50-14P
Dimensions
Class Width
36"
Width
35.35 inch(es) / 89.8 cm
Height
36.22 inch(es) / 92 cm
Depth (Without Handles)
23.62 inch(es) / 60 cm
Weight
251 lb(s) / 113.85 kg
Additional Dimensions
• Overall dimensions (W x H x D): 35 3/8” (89.8 cm) x 35 7/16” (90 cm) x 24 9/16” (62 cm)
• Adjustable range height: 35 7/16” (90 cm) min – 36 7/32” (92 cm) max
• Overall oven interior size (W x H x D): 23 13/16” (60.5 cm) x 13 25/32” (35 cm) x 16 59/64” (43 cm)
• Adjustable range height: 35 7/16” (90 cm) min – 36 7/32” (92 cm) max
• Overall oven interior size (W x H x D): 23 13/16” (60.5 cm) x 13 25/32” (35 cm) x 16 59/64” (43 cm)
