Specifications
General
Series Name
Gust II
Blower Included
Yes
Airflow
600 CFM
Style
Standard
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Under-Cabinet
Features
Technologies
Airflow Control Technology™ (ACT™)
Ducting Information
• 7" Round or 3-1/4" x 10"
• Vertical Internal Blower: 3-1/4" x 10"
• Vertical Internal Blower: 3-1/4" x 10"
Speeds
3 Speeds
Additional Information
• Blower CFM (Min. - Max.): 290 - 600 CFM
• Sones (Min. - Max.): 2 - 7 Sones
• ACT 390 CFM (Min. - Max.): 290 - 390 CFM
• ACT 290 CFM (Min. - Max.): 290 - 290 CFM
• ACT™ Technology: 390, 290
• Controls: Electronic Touch
• Auto Delay-Off: Yes
• Lighting: LumiLight LED, 6W x 2
• Dual-Level Lighting: Yes
• Filters: Hybrid Baffle x 2
• Sones (Min. - Max.): 2 - 7 Sones
• ACT 390 CFM (Min. - Max.): 290 - 390 CFM
• ACT 290 CFM (Min. - Max.): 290 - 290 CFM
• ACT™ Technology: 390, 290
• Controls: Electronic Touch
• Auto Delay-Off: Yes
• Lighting: LumiLight LED, 6W x 2
• Dual-Level Lighting: Yes
• Filters: Hybrid Baffle x 2
Electrical Information
Information
120 V, 60 Hz at Max. 2 A
Accessories
Optional
• Stainless Steel Telescopic Backsplash: AK1710
• Make-Up Air Kit: MUA006A
• Damper, 7" Round: AK00067
• Make-Up Air Kit: MUA006A
• Damper, 7" Round: AK00067
Dimensions
Class Width
30"
Width
29.92 inch(es) / 76.0 cm
Height
7.44 inch(es) / 18.9 cm
Depth
21.89 inch(es) / 55.6 cm
Additional Dimensions
• Mounting Height Range: 24" - 32"
• Mounting Height: Distance between the top of a 36" tall cooking surface and the bottom of the hood
• Mounting Height: Distance between the top of a 36" tall cooking surface and the bottom of the hood
Warranty
Warranty
• 3 Years Parts
• 1 Year Labor
• 1 Year Labor
