Specifications
General
Series Name
Vulcano Plus NRS
Blower Included
Yes
Airflow
600 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
• SRS Speed Reduction System
• NRS Technology
• NRS Technology
Additional Information
• Automatic cut-off timer
• Control: Electronic control
• Ducting type: External ducting/Recirculating
• Lighting: Dynamic Light (2700K - 5600K), Strip LED
• Filters: Metallic grease filter, removable and washable
• Filters: Baffle filter, removable and dishwasher safe
• Charcoal filter (optional)
• Notes: Recommended mounting height from cooking surface to hood bottom: 24" - 35"
• Control: Electronic control
• Ducting type: External ducting/Recirculating
• Lighting: Dynamic Light (2700K - 5600K), Strip LED
• Filters: Metallic grease filter, removable and washable
• Filters: Baffle filter, removable and dishwasher safe
• Charcoal filter (optional)
• Notes: Recommended mounting height from cooking surface to hood bottom: 24" - 35"
Electrical Information
Information
• Maximum consumption: 340 W
• Voltage/Frequency: 110-120V, 60Hz
• Connection type: Hood comes standard with Nema 5-15P power cord
• Voltage/Frequency: 110-120V, 60Hz
• Connection type: Hood comes standard with Nema 5-15P power cord
Dimensions
Class Width
30"
Width
29.84 inch(es) / 75.8 cm
Height
6.54 inch(es) / 16.6 cm
Depth
19.68 inch(es) / 50.0 cm
Weight
58 lb(s) / 26.31 kg
Shipping Dimensions
Width
41 inch(es) / 104.14 cm
Height
24 inch(es) / 60.96 cm
Depth
30 inch(es) / 76.2 cm
Weight
77.01 lb(s) / 34.93 kg
