Specifications
General
Series Name
Universal
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Type
Countertop
Cooktop
Burners/Elements
4
Power Output
• Zone 1 - Power: 2.10 kW
• Zone 2 - Power: 2.10 kW
• Zone 3 - Power: 2.10 kW
• Zone 4 - Power: 2.10 kW
• Zone 1 - Double booster power: 3.00 kW
• Zone 2 - Double booster power: 3.00 kW
• Power double booster 3° zone: 3.00 kW
• Zone 1 - Booster power: 2.50 kW
• Zone 4 - Double booster power: 3.00 kW
• Zone 2 - Booster power: 2.50 kW
• Zone 3 - Booster power: 2.50 kW
• Zone 4 - Booster power: 2.50 kW
• Left multi-zone - Booster power: 3.70 kW
• Booster power right Multizone: 3.70 kW
• Zone 2 - Power: 2.10 kW
• Zone 3 - Power: 2.10 kW
• Zone 4 - Power: 2.10 kW
• Zone 1 - Double booster power: 3.00 kW
• Zone 2 - Double booster power: 3.00 kW
• Power double booster 3° zone: 3.00 kW
• Zone 1 - Booster power: 2.50 kW
• Zone 4 - Double booster power: 3.00 kW
• Zone 2 - Booster power: 2.50 kW
• Zone 3 - Booster power: 2.50 kW
• Zone 4 - Booster power: 2.50 kW
• Left multi-zone - Booster power: 3.70 kW
• Booster power right Multizone: 3.70 kW
Burner/Element Size
• Zone 1 - Dimensions: 24.0x18.0 cm
• Zone 2 - Dimensions: 24.0x18.0 cm
• Zone 3 - Dimensions: 24.0x18.0 cm
• Zone 4 - Dimensions: 24.0x18.0 cm
• Left Multizone dimension: 38.5x23.0 cm
• Right multi-zone dimension: 38.5x23.0 cm
• Zone 2 - Dimensions: 24.0x18.0 cm
• Zone 3 - Dimensions: 24.0x18.0 cm
• Zone 4 - Dimensions: 24.0x18.0 cm
• Left Multizone dimension: 38.5x23.0 cm
• Right multi-zone dimension: 38.5x23.0 cm
Elements
Smoothtop
Features
Control Lock
Yes
Digital Display
Yes
Additional Information
• Control setting type: Touch control - Backlit white
• Finishing: Glass
• Glass: Eclipse ceramic
• Glass edge: Straight edge
• Time-setting options: Automatic switch-off
• Main on/off switch
• Limited power consumption mode
• Showroom mode
• Grill function
• Child safety lock
• Keep-warm automatic function
• Twin-zone option
• Quick start
• Quick level selection
• Residual heat indicator
• Protection from accidental start
• Finishing: Glass
• Glass: Eclipse ceramic
• Glass edge: Straight edge
• Time-setting options: Automatic switch-off
• Main on/off switch
• Limited power consumption mode
• Showroom mode
• Grill function
• Child safety lock
• Keep-warm automatic function
• Twin-zone option
• Quick start
• Quick level selection
• Residual heat indicator
• Protection from accidental start
Electrical Information
Information
• Nominal power: 7400 W
• Current: 33 A
• Voltage: 240 V
• Frequency: 60 Hz
• Current: 33 A
• Voltage: 240 V
• Frequency: 60 Hz
Dimensions
Class Width
24"
Width
23.62 inch(es) / 60 cm
Height
2.09 inch(es) / 5.3 cm
Depth
20.08 inch(es) / 51 cm
Weight
31.99 lb(s) / 14.51 kg
Shipping Dimensions
Width
26.19 inch(es) / 66.52 cm
Height
5.13 inch(es) / 13.02 cm
Depth
22.63 inch(es) / 57.47 cm
Weight
36.99 lb(s) / 16.78 kg
Warranty
Warranty
Full two-year warranty
