Zephyr 30-inch Vista Series Wall Hood Shell DVS-E30ASSX

ZephyrSKU: DVSE30ASSX
Low profile, curvy good looks and matchless power add up to a hood that’s at home in any kitchen. The... Low profile, curvy good looks and matchless power add up to a hood that’s at home in any kitchen. The cutting-edge Perimeter Aspiration System will increase air velocity and improve the capture of cooking contaminants for a cleaner cooking experience. Featuring Invisible Touch Controls that stay invisible until you need them, multiple blower options and illuminated with top-of-the-line LED lighting, the Vista Wall promises to seriously up your chef game. Optional remote control is available as an accessory. Blower sold separately. View more
Save $270.00 Price:
$2,789.00 $3,059.00
warranty product

Please select a warranty option

Avis sur la garantie légale

Features Specifications Documents
Features
CLEAN AIR
Clean Air is a feature that turns the blower on every 4 hours for 10 minutes to remove stagnant air in the kitchen. This feature is disabled by default and must be enabled by the user.
Specifications
General
Series Name
Visa
Blower Included
No
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
Perimeter Aspiration System
Ducting Information
• Vertical Single Internal Blower 6" Round
• Vertical In-Line/External Blower 10" to 8" Round
Speeds
3 Speeds
Additional Information
• Invisible Touch Controls
• Auto Delay-Off
• CleanAir Function
• Lighting LED, 5W x2
• Tri-Level Lighting
• Filter Aluminum Mesh x2
• Extension Duct Cover Option Up to 12' Ceiling
• Recirculating
Certifications and Approvals
Information
ADA with remote option
Accessories
Optional
• Internal Blower (CBI-290C) 200-290 CFM, 1.4-3 sones
• Internal Blower (CBI-600A) 240-600 CFM, 1.8-6 sones
• In-Line Blower (PBN-1000A) 500-1,000 CFM, sones NA
• External Blower (CBE-1000) 500-1,000 CFM, sones NA
• Recirculating Kit ZRC-00VS
• Remote Control 14000010
• Stainless Steel Telescopic Backsplash AK1710
• Make-Up Air Kit MUA006A (600 CFM), MUA008A (1,000 CFM)
Dimensions
Class Width
30"
Width
29.94 inch(es) / 76.04 cm
Height
25.5 inch(es) / 64.77 cm
Depth
18.87 inch(es) / 47.94 cm
Warranty
Warranty
2 Year Parts, 1 Year Labor
UPC
UPC#
646328008917
Documents
Installation Guide
Owners Manual
Product Specifications
Dimensions Sheet
