Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
Additional Features
POWERWAVE™ 3-PHASE BLOWER TECHNOLOGY
Delivers best-in-class performance with unparalleled quiet operation. It provides more power while minimizing noise and improving efficiency.
ZEPHYR CONNECT APP
Zephyr Connect App allows you to control your range hood from anywhere using your mobile device. It includes real time diagnostics and provides important product information. All you need is a WiFi connection with access to the internet. It seamlessly integrates with your smart devices such as Amazon Alexa or Google Home smart speaker for voice activation. Available to download from Google Play or the App Store.
Specifications
General
Series Name
• Venezia Wall
• Core Collection
• Core Collection
Blower Included
Yes
Airflow
700 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
• ACT™ Technology
• PowerWave™ 3-Phase Blower Technology
• Zephyr Connect App Compatible
• Alexa and Google Home Compatible
• PowerWave™ 3-Phase Blower Technology
• Zephyr Connect App Compatible
• Alexa and Google Home Compatible
Ducting Information
• Vertical Internal Blower
• 8" Round
• 8" Round
Speeds
• 6 Speeds
• Min. - Max. CFM: 200 - 700
• Min. - Max. Sones: 0.8 - 6
• ACT 590 CFM (Min. - Max.): 200 - 590
• ACT 390 CFM (Min. - Max.): 200 - 390
• ACT 290 CFM (Min. - Max.): 200 - 290
• Min. - Max. CFM: 200 - 700
• Min. - Max. Sones: 0.8 - 6
• ACT 590 CFM (Min. - Max.): 200 - 590
• ACT 390 CFM (Min. - Max.): 200 - 390
• ACT 290 CFM (Min. - Max.): 200 - 290
Additional Information
• Proximity Touch Controls
• Auto Delay-Off
• CleanAir Function
• Lighting: LumiLight LED, 6W x2
• Tri-Level Lighting
• Filters: Baffle x2
• Recirculating Option
• Extension Duct Cover Option: Up to 12' Ceiling
• ADA Compliant with Zephyr Connect or Remote
• Auto Delay-Off
• CleanAir Function
• Lighting: LumiLight LED, 6W x2
• Tri-Level Lighting
• Filters: Baffle x2
• Recirculating Option
• Extension Duct Cover Option: Up to 12' Ceiling
• ADA Compliant with Zephyr Connect or Remote
Electrical Information
Information
120V, 60Hz at Max. 5A
Accessories
Optional
• Wireless Remote Control: 14000005
• Recirculating Kit: ZRC-03VE
• Extension Duct Cover: Z1C-01VE
• Make-Up Air Kit: MUA008A
• Recirculating Kit: ZRC-03VE
• Extension Duct Cover: Z1C-01VE
• Make-Up Air Kit: MUA008A
Dimensions
Class Width
36"
Width
35.87 inch(es) / 91.12 cm
Height
27 inch(es) / 68.58 cm
Depth
24 inch(es) / 60.96 cm
Additional Dimensions
Mounting Height Range: 24" - 34"
Warranty
Warranty
• 1-Year for labor
• 3-Year for parts
• 3-Year for parts
UPC
UPC#
646328008481
