Features
CLEAN AIR
Clean Air is a feature that turns the blower on every 4 hours for 10 minutes to remove stagnant air in
the kitchen. This feature is disabled by default and must be enabled by the user.
Specifications
General
Series Name
Layers
Blower Included
No
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Technologies
Perimeter Aspiration System
Ducting Information
• Vertical Single Internal Blower 6" Round
• Vertical In-Line/External Blower 10" to 8" Round
• Vertical In-Line/External Blower 10" to 8" Round
Speeds
3 Speeds
Additional Information
• Invisible Touch Controls
• Auto Delay-Off
• CleanAir Function
• Lighting LED, 5W x4
• Tri-Level Lighting
• Filter Aluminum Mesh x1
• Recirculating
• Extension Duct Cover Option Up to 12' Ceiling
• Auto Delay-Off
• CleanAir Function
• Lighting LED, 5W x4
• Tri-Level Lighting
• Filter Aluminum Mesh x1
• Recirculating
• Extension Duct Cover Option Up to 12' Ceiling
Certifications and Approvals
Information
ADA with remote option
Accessories
Optional
• Internal Blower (CBI-290C) 200-290 CFM, 1.4-3 sones
• Internal Blower (CBI-600A) 240-600 CFM, 1.8-6 sones
• In-Line Blower (PBN-1000A) 500-1,000 CFM, sones NA
• External Blower (CBE-1000) 500-1,000 CFM, sones NA
• Recirculating Kit ZRC-00VS
• Remote Control 14000010
• Duct Cover - Stainless Steel Z1C-00VS
• Make-Up Air Kit MUA006A (600 CFM), MUA008A (1,000 CFM)
• Internal Blower (CBI-600A) 240-600 CFM, 1.8-6 sones
• In-Line Blower (PBN-1000A) 500-1,000 CFM, sones NA
• External Blower (CBE-1000) 500-1,000 CFM, sones NA
• Recirculating Kit ZRC-00VS
• Remote Control 14000010
• Duct Cover - Stainless Steel Z1C-00VS
• Make-Up Air Kit MUA006A (600 CFM), MUA008A (1,000 CFM)
Dimensions
Class Width
42"
Width
41.94 inch(es) / 106.52 cm
Height
29.81 inch(es) / 75.71 cm
Depth
22 inch(es) / 55.88 cm
Warranty
Warranty
2 Year Parts, 1 Year Labor
UPC
UPC#
646328008870
